Dahua HAC-B1A21P-U-0360B
Dahua HAC-B1A21P-U-0360B 2mp 3.6mm Sabit Lens 1080p IR Bullet AHD Kamera - Görsel 2
Dahua HAC-B1A21P-U-0360B 2mp 3.6mm Sabit Lens 1080p IR Bullet AHD Kamera - Görsel 3
, ,

Dahua HAC-B1A21P-U-0360B 2mp 3.6mm Sabit Lens 1080p IR Bullet AHD Kamera

Dahua
Stok Durumu:

Stokta
Favori Listeme Ekle

874,03₺ KDV Dahil

Stokta

Dahua HAC-B1A21P-U-0360B 2mp 3.6mm Sabit Lens 1080p IR Bullet AHD Kamera

HAC-B1A21-U

2MP IR HDCVI Fixed-focal Bullet Camera

> Max. 30 fps@1080p.

> Smart IR Illumination.

> 30 m illumination distance.

> 3.6 mm fixed lens

> CVI/CVBS/AHD/TVI switchable.

> IP67, 12 VDC.

prapazar.com pazaryeri woocommerce entegrasyonu

Camera
Image Sensor 2 MP CMOS
Max. Resolution 1920 (H) × 1080 (V)
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25 s–1/100,000 s;
NTSC: 1/30 s–1/100,000 s
Min. Illumination 0.02 lux@F2.0 (Color, 30 IRE)
0.002 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio >65 dB
Illumination Distance 30 m (98.43 ft)
Illuminator On/Off Control Auto/Manual
Illuminator Number 2 (IR light)
Angle Adjustment Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Lens Mount M12
Focal Length 3.6 mm
Max. Aperture F2.0
Field of View 3.6 mm: H: 80°; V: 43°; D: 94°
Iris Control Fixed
Close Focus Distance 3.6 mm: 0.8 m (2.62 ft)
DORI Distance Lens Detect Observe Recognize Identify
3.6 mm 55.0 m
(180.45 ft)		 22.0 m
(72.18 ft)		 11.0 m
(36.09 ft)		 5.5 m
(18.04 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Video
Video Frame Rate CVI:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
AHD:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
TVI:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
CVBS:
PAL: 960H
NTSC: 960H
Resolution 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/Night Auto(ICR)/Color/B/W
BLC BLC; DWDR
WDR DWDR
White Balance Auto
Gain Control Auto
Noise Reduction 2D NR
Illumination Mode Smart IR
Certification
Certifications CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035
Port
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply 12 VDC ± 30%
Power Consumption Max 2.8 W (12 VDC, IR on)
Environment
Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity <95% (RH), non-condensing
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity <95% (RH), non-condensing
Protection IP67
Anti-corrosion Level Basic Protection
Structure
Casing Material Plastic
Product Dimensions 146.1mm × 70.0 mm × 69.8mm (5.75″ × 2.76″ × 2.75″)
Net Weight 0.15 kg (0.33 lb)
Gross Weight 0.23 kg (0.51 lb)
Installation Wall mount; ceiling mount; vertical pole mount
Stok kodu: HAC-B1A21-U-0360B-Kamtek-Depo Kategoriler: , , Etiketler: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,
Marka

Dahua
Çözünürlük

2 Megapiksel
Kamera Türü

BULLET AHD Kamera
Lens Değeri

3.6mm
Lens Türü

Sabit lens
Ses Özelliği (ıp kamera)

Yok

Dahua HAC-B1A21P-U-0360B 2mp 3.6mm Sabit Lens 1080p IR Bullet AHD Kamera

HAC-B1A21-U

2MP IR HDCVI Fixed-focal Bullet Camera

> Max. 30 fps@1080p.

> Smart IR Illumination.

> 30 m illumination distance.

> 3.6 mm fixed lens

> CVI/CVBS/AHD/TVI switchable.

> IP67, 12 VDC.

prapazar.com pazaryeri woocommerce entegrasyonu

Camera
Image Sensor 2 MP CMOS
Max. Resolution 1920 (H) × 1080 (V)
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25 s–1/100,000 s;
NTSC: 1/30 s–1/100,000 s
Min. Illumination 0.02 lux@F2.0 (Color, 30 IRE)
0.002 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio >65 dB
Illumination Distance 30 m (98.43 ft)
Illuminator On/Off Control Auto/Manual
Illuminator Number 2 (IR light)
Angle Adjustment Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Lens Mount M12
Focal Length 3.6 mm
Max. Aperture F2.0
Field of View 3.6 mm: H: 80°; V: 43°; D: 94°
Iris Control Fixed
Close Focus Distance 3.6 mm: 0.8 m (2.62 ft)
DORI Distance Lens Detect Observe Recognize Identify
3.6 mm 55.0 m
(180.45 ft)		 22.0 m
(72.18 ft)		 11.0 m
(36.09 ft)		 5.5 m
(18.04 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Video
Video Frame Rate CVI:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
AHD:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
TVI:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
CVBS:
PAL: 960H
NTSC: 960H
Resolution 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/Night Auto(ICR)/Color/B/W
BLC BLC; DWDR
WDR DWDR
White Balance Auto
Gain Control Auto
Noise Reduction 2D NR
Illumination Mode Smart IR
Certification
Certifications CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035
Port
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power
Power Supply 12 VDC ± 30%
Power Consumption Max 2.8 W (12 VDC, IR on)
Environment
Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity <95% (RH), non-condensing
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity <95% (RH), non-condensing
Protection IP67
Anti-corrosion Level Basic Protection
Structure
Casing Material Plastic
Product Dimensions 146.1mm × 70.0 mm × 69.8mm (5.75″ × 2.76″ × 2.75″)
Net Weight 0.15 kg (0.33 lb)
Gross Weight 0.23 kg (0.51 lb)
Installation Wall mount; ceiling mount; vertical pole mount
